Dragino LoRaWAN Asset Tracker – TrackerD-LS

TrackerD-LS is an open-source LoRaWAN Asset Tracker based on ESP32 MCU and Semtech LoRa Wireless Chip. It can get the location data via GPS and set it to an IoT server via the LoRaWAN network.

TrackerD-LS supports Motion Detection. When there is motion, TrackerD-LS can send data more frequently, saving power when no motion is detected.

The LoRa wireless technology used in TrackerD-LS allows users to send data and reach extremely long ranges at low data rates. It provides ultra-long-range spread spectrum communication and high interference immunity while minimizing current consumption. It targets professional tracking services.

When there is no LoRaWAN network, TrackerD-LS can save the location data. It will send these data to the IoT server when there is LoRaWAN network coverage.

TrackerD-LS is equipped with a 3000mAh Li-on rechargeable battery and solar Panel, which allows the device to be used for many years. Each TrackerD-LS has a worldwide unique OTAA key to join the LoRaWAN network.

TrackerD-LS is program friendly. Developers can use Arduino IDE to customize the software of TrackerD-LS to fit their IoT solution.

• LoRaWAN 1.0.3 Class A
• ESP32 PICO D4
• SX1276/78 Wireless Chip
• Arduino IDE Compatible
• Open-source hardware/software
• Regular/ Real-time GPS tracking
• Built-in 3 axis accelerometer.
• Motion sensing capability
• Power Monitoring
• Charging circuit via USB port
• 3000mA Rechargeable Li-on Battery + Solar Panel
• Datalog

Applications:

• Logistics and Supply Chain Management
• Asset Tracking
